Zoom R12 Multitrak

Compact Multi-Track Digital Recorder
  • Zoom R12 Multitrak
  • Zoom R12 Multitrak
  • Zoom R12 Multitrak
  • Zoom R12 Multitrak
  • Zoom R12 Multitrak
  • Zoom R12 Multitrak
  • Zoom R12 Multitrak
  • Zoom R12 Multitrak
EUR 279.00
MSRP: EUR 329.00
Incl. VAT, free shipping in Germany
Musical freedom. Battery powered.
Product Rating4.3 out of 5 | 1 review |   Write a review

Description

The R12 was designed for musicians who live to make music. And who want the freedom to make music wherever they are. Thanks to its compact and portable design, you can record, edit and mix songs without the need for a computer. The R12's full-colour LCD touchscreen lets you cut, copy, loop and edit tracks with ease. The R12 features extremely clean preamps that you'll love the sound of. With two XLR/TRS inputs and eight audio tracks, the R12 is recommended for recording everything from demos to songs ready for release.

Supplied items

R12 MultiTrak
AD-17 AC Adapter
USB Cable
Quick Tour Guide

Attributes

Product Dimensions
Depth 158mm
Width 256mm
Height 61mm
Product Details
Product Number 240039
Brand Zoom
Series R
Category Compact Multi-Track Digital Recorder
Brand Category Zoom - Compact Multi-Track Digital
Relevancy rank 4 of 8
Date December 2022
Dimension
Weight 1kg
Box Width 256mm
Gross Weight 1.1kg

Properties

- Multi-track digital recorder with up to 8 tracks of recording.
- 2.4” Full Color LCD touchscreen display with easy touch and swipe editing
- User friendly graphic interface with on-board editing capabilities
- Battery Powered up to 5 hours (4 AA’s)
- 2 XLR / TRS Combo inputs - with phantom power and HI-Z on input 1
- Send effects channel with 4 options: Reverb, Delay, Chorus, or Guitar Lab preset (choose up to 3 effects from our guitar effects collection including distortions, modulation effects, spacial effects, and much more)
- Built-in compressor for inputs 1 and 2
- Pan and 3-band EQ for each track
- Sequence play - for using backing tracks in a live setting
- Drum loops (150 preloaded)
- Records directly to SDXC cards
- Built-in USB-C audio interface (2-in / 2-out or 2-in/4out) with control surface function

- Weight: 1.000kg
- Height: 61mm
- Width: 256mm
- Depth: 158mm

Specifications

- Inputs: MIC/LINE (mono): 2
Outputs:
- Master Out: 1
- Phones: 1
MIC/LINE (mono):
- Connectors: 2 XLR/TRS combo jacks (Balanced, XLR: 2 HOT / TRS: TIP HOT)
- Input gain: +6 ~ +50 dB
- Input impedance: XLR: 3.9 kΩ TRS: 3.9 kΩ/1 MΩ (when Hi-Z ON, INPUT 1 only)
- Phantom power: +48 V (switchable separately for INPUTS 1 and 2)
- Equivalent input noise: –121 dBu or less (IHF-A) at +50 dB/150 Ω input
- Frequency response: −1.0/+0.5 dB: 20 Hz – 20 kHz
MASTER OUT:
- Connectors: 2 TRS phone jacks (balanced)
- Maximum output level: +14 dBu
- Output impedance: 200 Ω
PHONES:
- Connectors: 1 stereo 3.5mm mini jack
- Maximum output level: 45 mW + 45 mW (into 32 Ω load)
- Output impedance: 10 Ω
RECORDER:
- Maximum simultaneous recording tracks: 2
- Maximum simultaneous playback tracks: 8
- Recording format: 44.1kHz, 16/24-bit, mono/stereo WAV
Recording media:
- Cards compatible with microSDHC specifications 4 GB – 32 GB
- Cards compatible with microSDXC specifications 64 GB – 1 TB
TRACK SETTINGS:
- EQ: High: 10 kHz, ±12 dB, shelving; Middle: 2.5 kHz, ±12 dB, peaking; Low: 100 Hz, ±12 dB, shelving
- Pan: L100 – R100
EFFECTS:
- Input Dynamics: Comp/Limiter/Gate
Patch memory effects:
- 3 types can be used simultaneously
- 50 patch memories
- Guitar Lab supported
- Can be assigned and used as an insert (input) or send effect
- Dedicated send effects: 10 types of spatial effects
- TUNER: Chromatic/Guitar/Bass/Open A/Open D/Open E/Open G/DADGAD
CLICK (METRONOME):
Time signatures: 3/4, 4/4, 6/8
Tempo range: 40.0 – 250.0 BPM
RHYTHM LOOPS:
- Sound source format: PCM
- Number of loops: 150
SYNTH:
- Sound source format: FM
- Polyphony: 8
- Number of sound types: 18 (and a PCM drum kit)
- DISPLAY: 2.4" (320×240) full-color touchscreen LCD
- Connector: USB Type-C
- Note: Use a USB cable that supports data transfer. USB bus power is supported.
Audio interface function:
2-in/2-out or 2-in/2-out (iPad):
USB 2.0 Full Speed
44.1 kHz, 16/24-bit
2-in/4-out:
USB 2.0 High Speed
44.1 kHz, 16/24-bit
Mass storage function:
- Device: USB 2.0 High Speed (5 V/200 mA power supplied when host)
- Guitar Lab connection: USB 1.1 Full Speed
- DAW connection (control surface): USB 1.1 Full Speed
Mass storage function:
- Host: USB 2.0 High Speed (5V/200 mA power supplied)
- USB MIDI keyboard connection: USB 1.1 Full Speed (5 V/200 mA power supplied)
POWER:
- Batteries: 4 AA (alkaline, lithium, or rechargeable NiMH)
- AC adapter: ZOOM AD-17 (5V/1.0A)
ESTIMATED CONTINUOUS OPERATION TIME USING BATTERIES:
- During playback with +48V off and 32Ω headphone load
- Alkaline batteries: about 5 hours
- NiMH batteries (1900 mAh): about 5 hours
- Lithium batteries: about 11 hours
- • The above values are approximate. • Continuous battery operation times were determined using in-house testing methods. They will vary greatly according to use conditions.
- POWER CONSUMPTION: 5 W maximum
- WEIGHT (including batteries): 827 g

Reviews (1)

Overall reviewProduct Rating
Operation:  Product Rating
Features:  Product Rating
Sound:  Product Rating
Product Rating
nobody
Product Rating
1 customer
Product Rating
nobody
Product Rating
nobody
Product Rating
nobody

Brand

Zoom is a reputable brand in the music and audio industry, specializing in digital audio recorders, multi-track recorders, and audio equipment for musicians, sound engineers, and content creators. Their products, like the Zoom H series portable recorders, are popular for their high-quality audio recording capabilities and portability, making them ideal for field recording, music production, and podcasting. Zoom has earned a strong reputation for its innovative and user-friendly audio solutions.
