RetroKits RK-006 (Orange)

DAW/DAWLESS You can use the RK-006 completely standalone with the same ease of using a 2-in, 10-out thru hub (with usb-standalone hosting and port filtering benefits), or you can use it as a 2-in, 10-out USB MIDI interface on your favourite platform/DAW (PC / MAC / Linux / Android / iOS (on iOS you need the apple usb connection cable) Just use one of the ten presets or configure and store your own custom configurations in the RK-006 via our webMIDI-settings-interface. MIDI MODE Every output port on the RK-006 can be individually set to send out full MIDI or Gate pulses, making a lovely hybrid use of it’s 3.5mm TRS connectors: You can connect DIN5 MIDI Gear via the included TRS-A to DIN5 cables or just plug in a plain ‘stereo minijack audio cable’ (preferably shielded) to sync up modular gear or even ‘minijack-MIDI’ devices like the Korg Electribe or NTS-1 and such. In MIDI mode you can apply MIDI Channel/Clock filtering and even clock modifiers (‘Multiclock’, allowing creative use of an abundance of sequencer gear which are available nowadays. Cou can even chain multiple MIDI devices together. Of course the RK-006 can also power our advanced RK-002 Smart MIDI processing cable as well so you can use it as a MIDI FX chain. GATE MODE When you set a port to Gate mode the MIDI-Tempo-to-Gate multiclock is still available. This together with an assignable Run/Stop signal allows synchronisation of devices like older Sync24/DINSync units as the TR-808, TR-303 and TR-606 (just to name a few) but also newer ones like the Moog DFAM and Teenage Pocket Operators and anything inbetween; Directly from your MIDI device. Gate signals can be triggered via a MIDI clock signal but also via MIDI Notes, adding the ability to bridge MIDI controller pads and modular gear. MASTER CLOCK GENERATOR The one-button on the RK-006 can be used to tap in a master clock or change presets on the RK-006 routing. You can also use it to switch from seemingly a MIDI merger/thru box to e.g. an independent dual-brain setup or one-big-master-gate-clocks-generator. USB STANDALONE HOST By using a simple (and included) OTG Adapter cable you can even connect plain 5V power and a USB hub to the RK-006 and host multiple USB-MIDI devices. The RK-006 will interconnect them and merge them together with the existing hardware ports. And because one USB-cable can route a whole lot more than just a MIDI-In or MIDI-Out we added extra filtering to specifically target these USB devices as well. And while in the USB area: You can even plug in a USB Memory Stick with prepared MIDI files (also called ‘SMF’). You can export these files on a DAW and playback these prepared tracks on your DAWless system, ready to play or clock-slave on your standalone sequencer of choice and play along live with it. This might already be too much info, but the story does not finish there quite yet: USB MIDI INTERFACE All the above can take place in the DAWless area BUT….You can also connect the RK-006 to e.g. a Desktop computer or iPad (note that iOS do need Apple’s USB2Lightning cable) and enjoy all the RK-006 ports independently addressable on your DAW! This means: - 10 separate MIDI outputs, every one of them can accommodate 16 MIDI devices - 2 separate MIDI Inputs Also, for usability’s sake we added: - Aggregate merged MIDI Out port to ALL 10 ports - Aggregate auto MIDI Merged Input
