Wharfedale Pro DP-2200
CHF 1599.00
CHF 1650.00
Will be ordered for you as quick as possible
Free delivery in Switzerland
| Product # | 254243 |
| Brand | Wharfedale Pro |
| Category | High-End Amplifier |
The Wharfedale Pro DP-2200 is a powerful 2-channel Class D amplifier that can power sophisticated speaker systems. With an output power of up to 9520 watts, you can be sure that no audio performance is too much for the Wharfedale Pro DP-2200. With various connection options on the back, including Hi-Z settings for 100V and 70V systems, this amplifier is a good choice for a wide variety of applications. Efficient cooling and an intelligent thermal protection circuit ensure that the Wharfedale Pro DP-2200 operates reliably and constantly over a long period of time.
STABLE UP TO 2 OHM
Stable up to 2 Ohms (*except DP-4030) and with enormous output power. The performance figures of the DP series are overwhelming. The nominal power is measured at THD = 1%, continuously sinusoidal 1 KHz, with all channels operating simultaneously. This allows multiple 8-Ω or 16-Ω loudspeakers to be operated with extreme power.
Power Factor Correction
Let's just do it to ourselves... and call it PFC instead! In combination with the switching power supplies in the amplifiers of the DP series, PFC increases amplifier efficiency and ensures smooth power output even with large fluctuations in the AC power supply. In the real world, it makes a huge difference in amplifier power and stability.
- - Super light weight - only 9.28 kg
- - 2 channels
- - 8 Ohm 2 x 2000 Watt
- - 4 Ohms 2 x 3400 Watts
- - 2 Ohms 2 x 4760 Watt
- - 16 Ohm Bridge 1 x 4000 Watt
- - 8 Ohm Bridge 1 x 6800 Watt
- - 4 Ohm Bridge 1 x 9520 Watt
- - 100 V Hi-Z: 2 x 3400 Watts
- - 70 V Hi-Z: 2 x 2400 Watts
- - Ultra-quiet fan with variable speed
- - Advanced protection circuit
- - Class D-Topology
- Model Name: DP-2200
- Stereo output power 8 Ohms: 2 x 2000 W
- Stereo output power 4 Ohms: 2 x 3400 W
- Stereo output power 2 Ohms: 2 x 4760 W
- Bridged mono output 16 Ohm: 1 x 4000 W
- Bridged mono output 8 ohms: 1 x 6800 W
- Bridged mono output 4 ohms: 1 x 9520 W
- 100V Hi-Z: 2 x 3400 W
- 70V Hi-Z: 2 x 2400 W
- Max. RMS Output voltage: 126.5 V
- Maximum input level: 21dBu (8.7 Vrms)
- Default gain: 24 dB
- Gain: 24dB to 42dB
- Cross-Talk: >90dB (20Hz - 1KHz, 8 Ohm)
- Signal/Noise ratio S/N: >105 dB (Default Gain, A-weighting, 20Hz - 1KHz, 8 Ohms)
- Distortion: <0.05% (at 10% output power 8 Ohms)
- Input impendance: 20kOhm symmetrical, 10kOhm unbalanced
- Frequency response: 20 Hz - 20 kHz (+/-0.5dB at 10% load at 8Ohm)
- Attenuation factor: >1000 (20Hz - 200Hz, 8 Ohms)
- Power amplifier topology: Class D
- Signal input: XLR sockets symmetrical
- Output power: speakON compatible
- Controller and switch front: AC switch on the front panel, channel gain knob per channel
- Rear regulator and switch: Parallel, Stereo & Bridge mode switches, Limiter switches
- Protection circuits: Thermal, overcurrent, output DC, short circuit protection
- Display Power, Protect, Signal, Limiter
- Cooling Fan with variable speed
- AC 90 - 260 V AC, 50 - 60 Hz
- Dimensions: 44mm x 485mm x 376mm
- Weight (net) 9.28 kg
- Weight (gross) 11.3 kg
- Stereo output power 8 Ohms: 2 x 2000 W
- Stereo output power 4 Ohms: 2 x 3400 W
- Stereo output power 2 Ohms: 2 x 4760 W
- Bridged mono output 16 Ohm: 1 x 4000 W
- Bridged mono output 8 ohms: 1 x 6800 W
- Bridged mono output 4 ohms: 1 x 9520 W
- 100V Hi-Z: 2 x 3400 W
- 70V Hi-Z: 2 x 2400 W
- Max. RMS Output voltage: 126.5 V
- Maximum input level: 21dBu (8.7 Vrms)
- Default gain: 24 dB
- Gain: 24dB to 42dB
- Cross-Talk: >90dB (20Hz - 1KHz, 8 Ohm)
- Signal/Noise ratio S/N: >105 dB (Default Gain, A-weighting, 20Hz - 1KHz, 8 Ohms)
- Distortion: <0.05% (at 10% output power 8 Ohms)
- Input impendance: 20kOhm symmetrical, 10kOhm unbalanced
- Frequency response: 20 Hz - 20 kHz (+/-0.5dB at 10% load at 8Ohm)
- Attenuation factor: >1000 (20Hz - 200Hz, 8 Ohms)
- Power amplifier topology: Class D
- Signal input: XLR sockets symmetrical
- Output power: speakON compatible
- Controller and switch front: AC switch on the front panel, channel gain knob per channel
- Rear regulator and switch: Parallel, Stereo & Bridge mode switches, Limiter switches
- Protection circuits: Thermal, overcurrent, output DC, short circuit protection
- Display Power, Protect, Signal, Limiter
- Cooling Fan with variable speed
- AC 90 - 260 V AC, 50 - 60 Hz
- Dimensions: 44mm x 485mm x 376mm
- Weight (net) 9.28 kg
- Weight (gross) 11.3 kg
| Product Dimensions | |
|---|---|
| Depth | 376mm |
| Width | 485mm |
| Height | 44mm |
| Product Details | |
|---|---|
| Product Number | 254243 |
| Brand | |
| Category | |
| Relevancy rank in Category High-End Amplifier | |
| Date | October 2025 |
| Product Quantity | |
|---|---|
| Unit | 1 piece(s) |
| Dimension | |
|---|---|
| Weight | 9.28kg |
| Box Width | 485mm |
