- Width: 1,430 mm (56-5/16")
- Height: With music rest closed: 931 mm (36-5/8"), With music rest raised: 1,093 mm (43-1/16"), With lid up: 1,580 mm (62-3/16")
- Depth: 1,237 mm (48-11/16")
- Weight: 133 kg (293 lb, 3 oz)
- Packing Box Width: 1,570 mm (61-13/16")
- Packing Box Height: 620 mm (24-13/32")
- Packing Box Depth: 1,410 mm (55-33/64")
KEYBOARD:
- Number of Keys: 88
- Type: GrandTouch™ Keyboard: wooden keys (white only), synthetic ebony and ivory key tops, escapement
- Touch Sensitivity: Soft2/Soft1/Medium/Hard1/Hard2/Fixed
- 88-key Linear Graded Hammers: Yes
- Counterweight: Yes
PEDAL:
- Number of Pedals: 3: Damper (with half-pedal function), Sostenuto, Soft
- GrandTouch Pedals: Yes
- GP Response Damper Pedal: Yes
- Functions: Sustain, Sostenuto, Soft, Glide, Style Start/Stop, Volume, etc.
- Type: Depending on the Smart Device
- Size: Depending on the Smart Device
- Language: 26 Languages (English, Japanese, Germany, French, Spanish, etc.)
- Panel Language: English
- Key Cover Style: Sliding
- Music Rest: Yes
- Music Clips: Yes
- Piano Sound: Yamaha CFX, Bösendorfer Imperial
- Binaural Sampling: Yes (“CFX Grand” and “Bösendorfer” only)
- Key-off Samples: Yes
- Smooth Release: Yes
- Virtual Resonance Modeling (VRM): Yes
- Grand Expression Modeling: Yes
- Number of Polyphony (Max.): 256
- Number of Voices (Preset): 872 Voices + 47 Drum/SFX Kits
- Compatibility: XG, GS, GM, GM2
- Reverb: 65 Types
- Master EQ: 5 Types
- Vocal Harmony: 44 Types
- Intelligent Acoustic Control (IAC): Yes
- Stereophonic Optimizer: Yes
- Dual/Layers: Yes
- Split: Yes
- Number of Preset Styles: 525
- Style Control: INTRO x 1, ENDING x 1, MAIN x 4, FILL IN x 4
- Number of Preset Songs: 403
RECORDING:
- Number of Songs: Depending on the Smart Device
- Number of Tracks: 16
- Data Capacity : Depending on the Smart Device
Compatible Data Format:
- Playback: SMF (Format 0 & 1), XF
- Recording: SMF (Format 0)
- Piano Room: Yes
- Lesson/Guide: Correct Key, Any Key, Karao-Key, Your Tempo
- Guide Lamp: Stream Lights (4 steps)
USB Audio Recorder:
Recording: WAV/AAC
Playback: Supported format by the Smart Device
USB Audio:
- Time Stretch : Yes
- Pitch Shift: Yes
- Vocal Cancel: Melody Suppressor
Overall Controls:
- Metronome: Yes
- Tempo Range: 5 – 500, Tap Tempo
- Transpose: -12 - 0 - 12
- Tuning: 414.8 – 440.0 – 466.8 Hz (0.2 Hz increments)
- Scale Type: 9
- Audio to Score: Yes
- Registration Memory: Yes
- Bluetooth: Audio/MIDI (varies by country)
- Storage External Drives: Depending on the Smart Device
CONNECTIONS:
- Headphones: Standard stereo phone jack (× 2)
- Microphone: Mic/Line In, Input Volume
- MIDI: IN, OUT, THRU
- AUX IN: Stereo Mini jack
- AUX OUT: Standard phone jack (R, L/L+R)
- AUX Pedal: Yes
- USB TO DEVICE: Yes
- DC IN: Yes
- Amplifiers: (50 W + 50 W+ 40 W) × 2
- Loudspeaker: (16 cm + 8 cm + 2.5 cm (dome) with Waveguide) × 2 + 20 cm, Spruce Cone Speaker, Twisted Flare Port
- Power Consumption: 75 W
- Auto Power Off: Yes
- Accessories: Owner’s Manual, USB cable(Type-C to Type-C), Online Member Product Registration, Power cord, Bench* (*May not be included depending on your area.)
