Refine the look, sound, and feel of Yamaha’s original Revstar guitar

Yamaha Revstar Professional RSP20 The Japanese-made RSP20 features carbon reinforcement in the neck and chambered body, dual humbucking pickups, 5-way switching, and a Focus Switch, providing exceptional versatility. Yamaha Revstar Professional RSP20 The Japanese-made RSP20 is available in three café racer-inspired finishes and features carbon reinforcement in the neck and chambered body to enhance tone, reduce weight, and ensure optimal balance. Dual humbucking pickups combined with a 5-position pickup selector and a passive push/pull Focus Switch provide uncommon versatility from a two-pickup guitar. A deluxe hardshell case is included. Yamaha Revstar Professional RSP20 The latest Revstar® guitars refine the look, sound, and feel of Yamaha’s original Revstar guitar series—and the three Japanese-made Professional Series models are the new flagships in the lineup. The RSP20 is available in three café racer-inspired finishes and features carbon reinforcement in the neck and chambered body—a concept developed using Yamaha’s exclusive Acoustic Design process to sculpt tone, reduce weight, and ensure optimal balance. Dual humbucking pickups, combined with a 5-position pickup selector and a passive push/pull Focus Switch, provide uncommon versatility from a two-pickup guitar. A deluxe hardshell case is included.

Hardshell case
Hex Wrench
Owners manual
Swing Tag

  • - Built in Japan
  • - 3 Café racer-inspired finishes
  • - Chambered maple and mahogany body
  • - Carbon-reinforced neck and body
  • - 2 Humbucking pickups
  • - 5-Position pickup selector
  • - Passive Focus Switch
  • - Hardshell case included

- Construction: Set-in
- Scale Length: 24-3/4” (628.6mm)
- Body Top: Maple
- Body Back: Chambered 2-Piece Mahogany, Carbon Reinforcement
- Body Finish: Gloss Polyurethane
- Neck Material: 3-Piece Mahogany, Carbon Reinforcement
- Neck Finish: Satin Polyurethane
- Fingerboard Materials: Rosewood
- Fingerboard Radius: 12" (304.8mm)
- Fret wire: Jumbo Stainless steel
- Number of frets: 22
- Nut material: PPS
- Neck Width @ 0 Fret / 12th Fret: 41.9 / 52.0 mm
- Thickness @1st Fret / 12th Fret: 21.0 / 23.9 mm
- Neck Pickup: VH5n Humbucker / Alnico V
- Bridge Pickup: VH5b Humbucker / Alnico V
- Controls: Master Volume, Master Tone (Push-Pull "Focus Switch")
- Pickup Switch: 5-Position Lever Switch
- Bridge: Tune-O-Matic
- String spacing: 10.5mm
- Tailpiece: Stopbar
- Tuning Machines: Die-Cast
- Pickguard: Swift Blue / Moonlight Blue: 3-Ply Cream, Sunset Burst: 3 Ply Black
- String gauge: D'Addario EXL110 / 0.010-0.046
- Case: Hardshell case
- Special Features: I.R.A. Treatment

Key attributes
Pickup Types
HH
Colour
Blue
Body Shape
Double Cutaway
Fingerboard Material
Rosewood
Body Material
Mahogany
Body
Guitar Construction
Solid Body
Orientation
Right-Handed
Top Material
Maple
Neck
Fingerboard Radius
12"
Neck Material
Mahogany
Guitar Scale
24.75"
Number of Frets
22
Fret Size
Jumbo
Nut Width
41mm
Nut Material
Plastic
Hardware
Bridge Type
Fixed
Hardware Finish
Chrome
Gold
String Gauge
.010"
Coil Split
No
Including Bag
Hard case
Double Cutaway Electric Guitar attributes
Guitar Finish
Gloss
Product Details
Product Number
236883
Brand
Yamaha
Yamaha sells their products throughout Europe from its European central warehouse. Products that we do not have in stock, but are available from stock at Yamaha Europe, are usually very reliably available within one week. If a product in the European warehouse is not available from stock, long delivery times are also possible. If in doubt, please ask us.
Series
Revstar
SubSeries
Professional
Category
Double Cutaway Electric Guitar
Brand Category
Yamaha - Double Cutaways
Relevancy rank in Category Double Cutaway Electric Guitar
82 of 262
Date
August 2022
Dimension
Gross Weight
13kg
